NVIDIA Warp + MjWarp: 7-Step Robotics Sim Tutorial
A practical walkthrough for using NVIDIA Warp and MjWarp to run massively parallel MuJoCo simulations on GPU and speed up robotics RL training.
September 30, 202614 min read
Robotics teams have been quietly begging for one thing since 2023: MuJoCo on the GPU without weird tradeoffs. And with NVIDIA Warp plus MjWarp, that's finally the default story for 2026.
This tutorial walks through installing both libraries, writing your first Warp kernel, running thousands of MuJoCo environments in parallel with MjWarp, and plugging the whole thing into a reinforcement learning loop. It's written for engineers who already know Python and a little PyTorch but haven't touched Warp before.
The short version: NVIDIA Warp is a Python framework that JIT-compiles regular-looking Python functions into CUDA kernels. MjWarp is a Warp-based backend for MuJoCo that runs simulation entirely on the GPU. Together they let you scale from one robot to tens of thousands of parallel environments on a single card.
And yes, it's genuinely fast. According to the Hugging Face blog post from NVIDIA, MjWarp can outperform CPU MuJoCo by more than an order of magnitude on training-scale batch sizes.
Warp plus MjWarp is the first path that keeps MuJoCo semantics, keeps PyTorch, and still delivers GPU throughput. That combination is why this stack is worth learning right now.
What You'll Build
By the end of this tutorial you'll have:
- A working Warp install with a custom vectorized kernel
- A batched MjWarp simulation stepping 4,096 humanoid environments in parallel
- A minimal PPO-style training loop wired to those parallel envs
- A basic profiling setup so you can see where time actually goes
Nothing fancy, nothing academic. Just the pieces you need to start replacing CPU-bound rollouts with GPU rollouts.
Prerequisites
Before you start, make sure you have:
- An NVIDIA GPU with compute capability 7.0 or higher (Turing, Ampere, Ada, Hopper, Blackwell). A 3060 works. A 4090 works better.
- CUDA 12.x drivers installed
- Python 3.10 or newer
- PyTorch 2.4+ with CUDA support
- Basic familiarity with MuJoCo XML models (helpful but not required)
If you're on a laptop iGPU or Apple Silicon, stop here. Warp needs CUDA. There's no CPU-only path that would be worth writing about.
Warp vs. MjWarp at a Glance
| NVIDIA Warp | MjWarp | |
|---|---|---|
| What it is | Python-to-CUDA JIT for custom kernels | GPU backend for MuJoCo physics |
| Written by | NVIDIA | Google DeepMind |
| Requires CUDA | Yes | Yes (uses Warp under the hood) |
| PyTorch interop | Zero-copy tensor sharing | Zero-copy via Warp |
| Best for | Custom rewards, observations, math kernels | Batched robot simulation at 1k-10k envs |
| Typical speedup vs CPU | Depends on kernel | 10-100x on training workloads |
Step 1: Install NVIDIA Warp
Installing Warp is a one-liner. The package ships prebuilt CUDA binaries so you don't need to compile anything.
Bash
pip install warp-lang
Verify the install with a quick sanity check:
Python
import warp as wp
wp.init()
print(wp.get_device())
print(f"Warp version: {wp.__version__}")
You should see something like cuda:0 and a version string in the 1.x range. If you see cpu only, your CUDA runtime isn't visible, and Warp will fall back to a much slower path.
Pro tip: run nvidia-smi first. Half of Warp "bugs" reported on GitHub turn out to be driver mismatches.
Step 2: Write Your First Warp Kernel
Warp kernels look like Python functions with a decorator. The library parses the AST and generates CUDA under the hood.
Python
import warp as wp
import numpy as np
wp.init()
@wp.kernel
def vector_add(a: wp.array(dtype=wp.float32),
b: wp.array(dtype=wp.float32),
out: wp.array(dtype=wp.float32)):
i = wp.tid()
out[i] = a[i] + b[i]
n = 1_000_000
a = wp.array(np.random.rand(n).astype(np.float32), device="cuda")
b = wp.array(np.random.rand(n).astype(np.float32), device="cuda")
out = wp.zeros(n, dtype=wp.float32, device="cuda")
wp.launch(vector_add, dim=n, inputs=[a, b, out])
wp.synchronize()
print(out.numpy()[:5])
A few things worth knowing here. The @wp.kernel decorator triggers JIT compilation on first call, so the first launch is slower than the ones after. And wp.synchronize() matters when you're timing anything, because kernel launches are asynchronous by default.
This is the same programming model you'll use later for custom reward functions or observation transforms inside your RL loop.
Step 3: Install MjWarp
MjWarp is distributed as a separate package. It depends on both Warp and the standard MuJoCo Python bindings.
Bash
pip install mujoco mujoco-warp
Check the install by loading the classic humanoid model:
Python
import mujoco
import mujoco_warp as mjw
model = mujoco.MjModel.from_xml_path("humanoid.xml")
data = mujoco.MjData(model)
mjw_model = mjw.put_model(model)
mjw_data = mjw.put_data(model, data, nworld=1)
print(mjw_data.qpos.shape)
The nworld argument is the whole point. It's the number of parallel simulation instances that share the same model but have independent state. This is where Warp earns its keep.
Step 4: Scale to Thousands of Parallel Environments
Switching from one environment to 4,096 is a single argument change:
Python
nworld = 4096
mjw_data = mjw.put_data(model, data, nworld=nworld)
for step in range(1000):
mjw.step(mjw_model, mjw_data)
wp.synchronize()
That's the whole loop. No batching code, no threading, no environment vectorization wrapper. Every field on mjw_data (positions, velocities, contact forces) is a Warp array with a leading nworld dimension.
On a modern Ada-generation NVIDIA card, nightly benchmarks from the MuJoCo Warp repo (recorded on an RTX 6000 Ada) show throughput in the millions of steps per second for standard MJCF models like humanoid. That's not a typo. The CPU version tops out around a few thousand steps per second on the same models.
But you'll pay for it in memory. 4,096 humanoids at fp32 will happily eat 8 to 12 GB of VRAM depending on contact configuration. If you OOM, cut nworld in half and try again.
Step 5: Connect to PyTorch for RL Training
Warp arrays share memory with PyTorch tensors via zero-copy conversion. This is the piece that makes end-to-end GPU RL actually pleasant.
Python
import torch
qpos_torch = wp.to_torch(mjw_data.qpos)
qvel_torch = wp.to_torch(mjw_data.qvel)
obs = torch.cat([qpos_torch, qvel_torch], dim=-1)
policy = torch.nn.Sequential(
torch.nn.Linear(obs.shape[-1], 256),
torch.nn.Tanh(),
torch.nn.Linear(256, model.nu),
).cuda()
action = policy(obs)
ctrl_warp = wp.from_torch(action, dtype=wp.float32)
mjw_data.ctrl.assign(ctrl_warp)
mjw.step(mjw_model, mjw_data)
No host-device copies. No numpy round-trips. The policy forward pass, the simulation step, and the reward computation all stay on the GPU.
This is where the throughput numbers start to matter for real training runs. PPO iterations that used to take minutes on CPU-vectorized MuJoCo commonly drop by more than an order of magnitude on GPU with MjWarp, and Isaac Lab now integrates MjWarp via Newton for exactly this reason. Your mileage will vary based on batch size and model complexity, but the direction is consistent.
Step 6: Write Custom Reward Kernels
One of the underrated wins here is writing rewards as Warp kernels instead of PyTorch ops. It avoids kernel launch overhead when the reward is simple element-wise math.
Python
@wp.kernel
def locomotion_reward(qvel: wp.array2d(dtype=wp.float32),
ctrl: wp.array2d(dtype=wp.float32),
reward: wp.array(dtype=wp.float32)):
i = wp.tid()
forward_vel = qvel[i, 0]
ctrl_cost = wp.float32(0.0)
for j in range(ctrl.shape[1]):
ctrl_cost += ctrl[i, j] * ctrl[i, j]
reward[i] = forward_vel - 0.1 * ctrl_cost
reward = wp.zeros(nworld, dtype=wp.float32)
wp.launch(locomotion_reward,
dim=nworld,
inputs=[mjw_data.qvel, mjw_data.ctrl, reward])
Why do it this way? Because you get a single fused kernel instead of five PyTorch ops with intermediate allocations. Not always faster for complex rewards, but for simple locomotion-style rewards it consistently is.
Step 7: Profile and Debug
Warp ships a built-in profiler that's genuinely useful. Use it before you start tuning anything.
Python
wp.ScopedTimer("sim_step", active=True)
with wp.ScopedTimer("sim_step"):
for _ in range(100):
mjw.step(mjw_model, mjw_data)
wp.synchronize()
For deeper analysis, run your script under Nsight Systems (nsys profile python train.py). You'll see the actual kernel timeline and can spot serialization bottlenecks like host-side reward computation or Python callbacks that break the async pipeline.
Common Pitfalls
A few things that trip up almost everyone the first week:
Forgetting wp.synchronize() when timing. Kernel launches return immediately. If you call time.time() right after wp.launch(), you're timing the launch, not the work.
Mixing devices silently. A tensor on cpu passed into a cuda kernel triggers an implicit copy every step. Use .device checks liberally.
Overallocating nworld. More environments isn't always faster because of memory bandwidth pressure. Sweep nworld from 256 to 8192 and find the throughput knee for your specific model.
Assuming MjWarp matches MuJoCo bit-exact. It's numerically close but not identical. Policies trained on one and evaluated on the other can behave slightly differently, especially at contact-heavy timesteps.
Testing Your Setup
Run this end-to-end sanity check before you invest in a real training script:
Python
import time
import mujoco
import mujoco_warp as mjw
import warp as wp
model = mujoco.MjModel.from_xml_path("humanoid.xml")
data = mujoco.MjData(model)
mjw_model = mjw.put_model(model)
mjw_data = mjw.put_data(model, data, nworld=4096)
wp.synchronize()
start = time.time()
for _ in range(1000):
mjw.step(mjw_model, mjw_data)
wp.synchronize()
elapsed = time.time() - start
steps_per_sec = 4096 * 1000 / elapsed
print(f"Throughput: {steps_per_sec:,.0f} steps/sec")
On a modern Ada-class GPU you should see millions of steps per second for the classic humanoid. If you're getting less than a few hundred thousand at 4,096 environments, something is wrong (usually a driver or memory issue).
Next Steps
Once this is working, the natural progressions are:
- Wire MjWarp into an existing RL framework like Isaac Lab or a custom PPO trainer
- Explore Warp's differentiable simulation features for gradient-based policy optimization
- Move to multi-GPU with
torch.distributedand per-rank env batches - Try sim-to-real transfer with domain randomization implemented as Warp kernels
MjWarp is still moving fast, so pin your versions if you're running production experiments. And keep an eye on the MuJoCo release notes because feature parity with the CPU version is improving basically every release.
GPU-native robotics simulation used to mean rewriting everything in Isaac Gym or accepting Brax's JAX-only ecosystem. Warp plus MjWarp is the first path that lets you keep MuJoCo semantics, keep PyTorch, and still get GPU throughput. That combination is why this stack is worth learning right now.
